The MSI GeForce RTX™ 5070 VANGUARD SOC graphics card is a powerhouse engineered for explorers, creators, and elite gamers alike. Designed with the spirit of futuristic innovation, the VANGUARD series boasts bold aerodynamic styling, fractured contours, and customizable RGB lighting
Equipped with DisplayPort 2.1b (x3) and HDMI™ 2.1b (x1) outputs, the card supports up to 8K at 120Hz or 4K at an astounding 480Hz, complete with G-SYNC®, Variable Refresh Rate (VRR), HDR, and full DirectX® 12 Ultimate and OpenGL 4.6 compatibility. A single 16-pin connector powers this 250W performance beast, and MSI recommends a 650W PSU for optimal headroom.
SPECIFICATIONS:
Graphics Processing Unit: NVIDIA® GeForce RTX™ 5070
Interface: PCI Express® Gen 5
Core Clocks:
Extreme Performance: 2655MHz (MSI Center)
Boost: 2640MHz
CUDA® CORES: 6144 Units
Memory Speed: 28Gbps
Memory: 12 GB GDDR7
Memory Bus: 192-bit
Output:
DisplayPort x 3 (v2.1b)
HDMI™ x 1 (As specified in HDMI™ 2.1b: up to 4K 480Hz or 8K 120Hz with DSC, Gaming VRR, HDR)
HDCP Support: Y
Power consumption: 250W
Power connectors: 16-pin x 1 (ATX 3.1 PSU recommended)
Recommended PSU: 650W
DirectX Version Support: 12 Ultimate
OpenGL Version Support: 4.6
Maximum Displays: 4
G-SYNC® technology: Y
Digital Maximum Resolution: 7680 x 4320
Card Dimension: 33.7 x 14 x 6.1 cm
Card Weight: 1503 g
WHAT’S IN THE BOX:
MSI GeForce RTX 5070 VANGUARD SOC 12GB Graphics Card x1
36 Months Warranty
